Chapter 2 Basic Operations 2-5
2. 3 Replacing Roll Media
Reference
(1) When the printer is running out of a roll media, the UI Screen will
display “Roll Replacement” sign.
Follow the later procedure (or as noted in the UI’s User Guide) to load a roll media.
Please refer to your KIP IPS Touch Screen Operator’s Guide for the UI screen.
(2) It is recommended that a tracing paper /
vellum roll is loaded to Roll Deck 3 or 4.
(3) This section describes how to install a roll media to Roll Deck 1.
The same procedure is applied to Roll Deck 2 / 3 / 4, unless otherwise noted.
Front Rear
Roll 1 Roll 2
Roll 3
Roll 4
NOTE
A paper mis-feed tends to occur just before out of a roll paper.
To Next Page
