Chapter 2 Basic Operations 2-11
8. Rotate the green knob (11) to the arrow direction (away from front) so that the feeding rollers
catch the leading edge.
9. Push Roll Deck (1) to firmly close it.
Roll 1
Roll 3
Roll 2
Roll 4
11
11
Front Deck
Roll 1 / 3
Rear Deck
Roll 2 / 4
NOTE
(1) Be sure to close Roll Deck fully until it locks at the correct position.
A paper jam may occur if it is not locked firmly.
(2) Be sure not to catch your finger in between Roll Deck drawers.
1 1
To Next Page
