Kipor IG2000 - Rocker Arm Dimensional Inspection

10.2 Inspection
● Rocker arm outer diameter
Standard(mm) Service limit(mm)
5.972-5.980 5.965
● Rocker arm inner diameter of inlet/exhaust valve
Standard(mm) Service limit(mm)
6.000-6.012 6.037
● Inner diameter of rocker arm bearing
Standard(mm) Service limit(mm)
6.000-6.012 6.037
53
