(4) Pull out rope thrum from starter outer shell hole completely, pass it through the handle and make a “8”
knot, then turn off handle cover. Loosen the reel to rebound the spring, take care not to allow the reel pop
out.
(5) Install the starter pallet and fix it with bolts.
(6) Pull the starter for several times, and check the ratchet wheel returning.
8.3 Inspection
(1) Ignition coil
● Attach the two leads of tester to the primary coil plug of ignition coil, and measure the primary
resistance of the ignition coil.
Primary resistance 0.8—1.3Ω
47
