11.5 Assembly of crankcase cover
1. Clear the remaining seal gum on the cylinder block and crankcase cover with cloth.
2. Smear seal gum on the cylinder block sealing face, as picture shows.
3. Reassemble the crankcase cover in the opposite direction of disassembly.
Caution
Install the crankcase cover on the cylinder block 3 minutes after smearing. Revolve the crankshaft if
necessary.
57
