ADJUSTINGTHEBRUSHROLLHEIGHT(cont)
Place the brush back into the nozzle making sure both
plasticBrushRollendsaresettothesamenumberof
notches (1, 2, or 3).
Replace the Rug Plate
o
26 by placing it on the front of the
bumper first and then pulling it over the bumper on rear of
Power Nozzle
o
25 . Secure the Rug Plate using the two latches
that hold it in place.
UsingtheL-shapedhandle,hookthebeltontotheBeltLifter
o
20 andturntheBeltLiftertotheleft(counter-clockwise)
until the red arrows line up. This will stretch the belt in prep-
aration for returning the nozzle to the Ultimate G. ❏
LIGHTBULBREPLACEMENT
IfthelightbulbinyourHeadlightAssemblyburnsout,
you may wish to contact your authorized Kirby
®
Distributor.
If you prefer to install a new light bulb yourself, use the
following procedure:
Turn off and unplug your Ultimate G. Raise the
HeadlightHood
o
21 . On the underside of the hood,
locate the horizontal slot in the center just above the
arrow. Insert a flat screwdriver in the slot and push until the
plastic lens loosens. Pop the lens off. ➤
LowertheHeadlightHood.Withyourforefingerand
thumb, gently wiggle the light bulb until it loosens.
Gently pull it out of the socket. Gently push a new
bulb into the opening. ➤
Beforeyoure-attachthelens,lookatthetwotabson
therearofthelens.Bothshouldfaceup.Insertthelens
into the lens opening and gently fit into place. ❏
Brush Roll Bristle Height Adjustment/Light Bulb Replacement
3
1
4
2
