over current or short circuit. Please cut off the power, and then turn on
again to continue charging.
If the charger tests out the temperature of the battery is too high
(over 60 ), it will stop charging, and the charger LED turns yellow.
After the temperature drops, remove the battery and re-put to
continue charging.
(2) Installing / Removing the Battery Pack
Match the two grooves of the battery pack
with the corresponding guides on the back of the
transceiver.
Slide the battery pack along the back of the
transceiver until the battery release latch on the
base of the transceiver locks.
To remove the battery pack, pull back on the
release latch and slide the pack away from the
transceiver ( Figure2).
(Figure2)
Caution:
Do not short-circuit the battery terminals or dispose the battery into
*
fire.
Never attempt to remove the casing from the battery pack.
*
Do not install the battery pack in the dangerous atmosphere, or
*
sparks will cause explosion.
To avoid explosion,please do not place the battery in the high
*
temperature areas.
(3) Installing the Antenna
Screw the antenna into the connector at the top of the
transceiver by holding the bottom of the antenna and
turn it clockwise until secure ( Figure3).
(4) Installing / Removing the Belt Clip
Match the belt clip with the corresponding grooves on the
battery,then press the belt clip downwards to lock it in place.
To remove the belt clip, slide up the belt clip by your nail or
tools (Figure4).
Remove the rubber cover and insert the speaker-microphone
plugs into the SP/MIC jacks.
(5) Installing the Optional Speaker / Microphone
(Figure3)
(Figure4)
