PT260 Service Manual

Appendix 2 Electronic Parts Lists

No. Part No. Descriptions Position Mark QTY

1 1IP1-M30C026FPGP MCU/CPU,R8C/24,M30C026FPGP#U0,52PIN,8 bits

chip,FLASH,ROHS

IC3 1

2 1IM1-AT24C08BN-SH Memory IC/AT24C08AN-SU27,ROHS IC2 1

3 1IS1-RDA1845 IC/RDA1845,PLL&IF&AF&TX&RX,ROHS IC1 1

4 1IS1-TA7368PLA TA7368PL,SSOP-10 U31 1

5 1IS1-NA019 Voice annunciation of Channel NA019,SOP8 IC4 1

6 1IS1-XC62FP3002PR Regulator IC/FP3002,SOT-89,ROHS IC6 1

7 1IL1-RC4558DR Double operation amplification RC4558DR,SOIC-8 U32 1

8 1IS1-LM358G-2 LM358G-2,SOP8 IC5 1

9 1DS1-BA592 BA592(S),SOD323 D21 1

10 1DS1-HSC277 Wave band switch,HSC277(HITACHI),ROHS D12 D11 2

11 1DS1-DAN222 Duodiode,SOT-423 D42 1

12 1DS1-1SS372 Duodiode,SOT-323 D41 1

13 1DS1-1SS362 Duodiode,SOT-423 D17 1

14 4PE1-16-F5-UG 1608, verdancy, ultrahigh bright,(TW-190UG) D61 1

15 4PE1-16-F2 0603,Red,19-21SURC/S530-A2/TR8,ROHS D62 1

16 1TT1-DTA144EE Chip fixed triode /DTA144EE(ROHM),ROHS Q25 1

17 1TT1-DTC144EE Chip fixed triode /DTC144EE(ROHM),ROHS Q62 Q28 Q61 Q33 Q31 Q24 6

18 1TT1-2SC3356-R24 Chip fixed triode /2SC3356,R24,ROHS Q19 1

20 1TT1-KTA1298-Y Chip fixed triode /KTA1298(Y),ROHS Q12 Q51 2

21 1TT1-2SC4181-L18 2SC4181-L18,SOT323 Q5 1

22 1TF1-2SK1588 Chip fixed FET/2SK1588(NEC),ROHS Q34 1

23 1TF1-2SK1824 Chip fixed FET/2SK1824,ROHS Q26 1

24 1TF1-2SK3475 Chip fixed FET/2SK3475,ROHS" Q22 1

25 1TF1-2SK3476 Chip fixed FET/2SK3476,ROHS Q21 1

26 3ST3-SKHLLBA010 Button switch/SKHLLBA010, ROHS K1 1

27 3ST3-IT-1101VLA-3260 Touch switch IT-1101VLA-3260,ROHS K4 K2 2

28 3SE3-RE08140AX-V01-A None SW3 1

29 2RS1-10-000O Sheet resistor /0402,0R±5%,ROHS R28 R61 R67 R619 L33 R92

C115 C114 R122 R117 C8

R52

30 2RS1-10-100J Sheet resistor /0402,10R±5%,ROHS R617 R319 R199 R214 R75 5

31 2RS1-10-101J Sheet resistor /0402,100R±5%,ROHS R412 R234 R49 3
