PT260 Service Manual
12
Ni-plated
18
7SMF-020040M-SZYB-N
M2*4 Cross round head machine
screw 13
Material: steel hardened, 2mm*4mm, cross round
head machine screw, metric coarse thread, nylon patch
19
7MHR-7025-05A-WO PT-3500S Earphone jack gasket 1
Material: silica gel, black, hardness: 55
°
20
7MHP-7025-09A-WO
PT-3500S Battery touch sheet
bracket 1 Material: ABS, black
21
7GCM-145158010-J
PT-3500S Battery waterproof gasket
1
Material: black PORON, mill finish, 14.5mm
＊
15.8mm
＊
1mm, adhesive tape with 3M glue
22
7MHC-1175-01B-N 3200 Battery touch sheet 2 Material: 0.25mm phosphor copper, Ni-plated
23
7SMF-020050M-MHHT-N1
M2*5 Torx thick head machine
screw 2
Material: Steel hardened, 2mm*5mm torx thick
Ni-plated machine screw, metric coarse thread. Head
diameter: 3.6*1.5
7SMF-025080M-SZYB-Z1
M2.5*8 Cross round head machine
screw 2
Material: steel hardened, 2.5mm*8mm cross round
head black Zn-plated machine screw, metric coarse
thread (belt clip)
Chapter 6 Adjustment
Make sure that all the equipments are grounded completely
before test/adjustment!
Make sure that the antenna connector is correctly connected
to the equipment or load.
The output of the transmitter must connect to the standard
signal source/cymometer/deviation meter/frequency spectrum
meter with the RF power attenuator！
Make sure that the receiver does not transmit when tested!
Make sure that the engineers and the equipments have the
reliable anti-static measurement during the
adjustment/test/maintenance.
6.1 Equipments and Software Needed for the Adjustment
The following table lists the equipments and software needed for
the adjustment and test.
Table 6.1: Equipments and software needed for the adjustment and
test
No. Name Parameter Requirement
1 PC
P2 above, compatible with IBM
PC
WINDOWS 98/ME/2600/XP
2 Programming software KSP260
3 Programming cable KSPL-02
4 Clone cable
KCL-01
5
DC regulated power
supply
Output voltage ： 7.5V ， output
current： 5A
6 RF power meter
Test range: 0.5 - 10W
Frequency range: 100MHz -
500MHz
Impedance: 50
SWR 1.2
7 Frequency meter
Frequency range: 0.1 - 600MHz
Frequency precision: better than
±1×10
-6
Sensitivity: better than 100mV
8 Deviation meter
Frequency range: DC - 600MHz
Test range: 0 - ±5kHz
9 Digital multimeter
Input impedance: 10M/V DC
above, capable of testing voltage,
current and impedance
10 Audio signal generator
Frequency range: 2 - 3000Hz
Output level: 1 - 500mV
11 RF power attenuation
Attenuation: 40dB or 50dB
Power: ＞10W
12 Standard signal source
Frequency range: 10MHz -
1000MHz
Output level: 0.1uV - 32mV
(-127dBm~-17dBm)
13 Oscilloscope
Frequency range: DC~20MHz
Test range: 10mV~20V
14 Audio voltage meter
Test range: 10mV~10V
Recommendation: The equipments of number 6, 7, 8, 10, 11,
12 can be replaced by HP8920 Comprehensive test equipment.
