8
7
BASIC OPERATION
5. Receive a Call
Release the PTT button to receive a call.
Your dealer can set CTCSS, DCS, 2 Tone signaling on your
radio channels by PC software. If you select a channel that has
been preset with the tone signaling, you will not hear any other
calls except those from your own system.
1.Switch On
Switch on the radio by turning the Power/Volume
switch clockwise
till a click is heard, then the radio will be in the
state of stand by and you will hear a beep if the
dealer has set it.
2.Adjust Capacity
Press the button preset as canceling squelch to
listen to the background noise and rotate the
Power/Volume switch to adjust capacity.
3.Select Channels
Rotate the channel selector to select channels.
You will hear voice from the speaker while
receiving proper signals.
As shown in the above right figure:
Zone 1 is the zone of current channel (8
zones from 0 to 7).
H is the transmit power of the channel, H
stands for high power, M for middle
power while L for low power.
CHANNEL 1 is the current channel (128
zones from 1 to 128).
P
4. Make a Call
To make a call, press PTT, and speak in normal
voice. Please keep your mouth 3~4 cm away from
the microphone.
6. Operation on menu:
press button to enter the menu or confirm any contents;
press button to return to the previous menu or cancel
the set. When entered the menu, select the sub-menu with the
channel selector , or .
The menu is as follows:
P
4
P
1
P
2
P
3
