12 | USING THE STAND MIXER ATTACHMENT
USING THE STAND MIXER ATTACHMENT
ASSEMBLING THE FRUIT AND VEGETABLE STRAINER
1
Slide the smaller end of the spring
and shaft assembly into the opening
on the large grind worm until it is
secured firmly in place.
2
Insert the large grind worm into the
grinder body.
3
Attach the strainer cone over the
exposed end of the large grind worm,
matching the tabs of the cone with
the notches in the grinder.
4
Place the ring onto the grinder body,
turning by hand until finger tight, but
not over-tightened.
5
Slide the strainer tray over the cone
and latch on the top of ring.
6
Place splash shield on strainer tray.
NOTE: The combination food pusher/
wrench is used for removal of the ring
only. To avoid damage to the attachment,
do not use the combination food pusher/
wrench to tighten the ring to the
grinder body.
