CommercialUnitParts
Illus.No.
 PartNo.Description
1 W10581080 Useand CareGuide
2 W10439369 Foot
3 W10354780 Bowl
4 240185 Pin,RetainingBowl
5 W10504114 BowlRetainer
6 3400018 Screw
7 BowlSupportandPins(RefertoColorVariationPartsPageforModelNumber) 
8 BaseandFootAssembly(RefertoColor
VariationPartsPageforModelNumber)
9 9708649 Foot
10 9703307 RetainingRing
11 9706787 BowlLiftRod
12 9237LiftRodSpring
13 9703439 Washer
14 8533907 Nut
15 ColumnandPins(RefertoColorVariationPartsPageforModelNumber)
16 W10376294 FlatBeater(Stainless)
17 W10462785 DoughHook(Stainless)
18 9706885 BowlLiftArm
19 W10600940 WireWhip
20 9703426 AdjustingCam
21 3400863 Screw

22 9706788 BowlLiftHandle
23 9706814 VentScreen
24 3400200 Screw

