KitchenAid KF26M22 - Remove Bowl Lift Mechanism

17. Commercial units have a screen that can
be removed and cleaned.(Fig. 18)
Fig. 18 Remove Commercial Screen
18. Remove the 7/16 lock nut that holds the
bowl lift handle and remove the washer
and spring.(Fig. 19)
Fig. 19 Remove Nut, Spring and Washer
19. Turn the Column over and remove the
small Phillips screw that runs through
the Bowl Lift Arm.(Fig. 20)
Fig. 20 Remove Screw
20. Hold the Lift Arm (white plastic sleeve)
with one hand and pull the Bowl Lift
Handle out with the other hand. Then
lift the Lift Arm up and out of the
Column.
21. Bowl lift mechanism parts(Fig. 21)
Fig. 21 Lift Arm Assembly
