KitchenAid
®

New Gen Stand Mixer Service/Repair Manual
Intended for Professional Service Technician Only
© 2016 KitchenAid
®
 CoversDomesticModel–KB26G1X,KF26M22,KF26M2C,KF26M2X,KG25H0W,KG25H0X,
KG25H3X,KL26M8X,KM25G0X,KP26KPRA,KP26M1FQ,KP26M1P,KP26M1XA,
KP26M1X,KP26M1XEP,KP26M1XFQ,KP26M1XQ,KP26M8X,KP26N9X,KT2651X,KV25G0X,
KV25H0X,KV25MCX,KV25MEX,
 InternationalModel–4KB25G1,4KG25H3X,4KP26M1X,4KV25H0X,8KP2670T,
Table of Contents
Subject Page(s)
Color Variation Parts Diagram 4
Base and Pedestal Diagram
6
Commercial Bowl Lift Diagram
7
Case, Gearing and Planetary Diagram
10
Important Service Workplace Safety Recommendations
24
Service Environment
24
Personal Protection
25
Electrical Considerations
25
Important Safeguards
25
Electrical Requirements
26
List of Tools Required
26
Testing the Stand Mixer
26
Service Procedures:
27
Removal of the Trim Band
27
Removal of the Upper Housing
27
Remove Control Board
28
Remove Transmission Housing
28
Remove 1
st
Stage Gear 28
Remove Motor
29
Remove Planetary
30
Removal of the Lower Housing
30
Remove Base
30
Remove Bowl lift Mechanism
31
Rebuilding the New Generation Stand Mixer
32
Replacing the Bowl Lift Mechanism
32
Replace Lower Housing
32
Replace Planetary
33
Replace Gears
33
Replace Transmission Cover
34
Replace Motor
34
Replace Control Board
35
Replace Upper Housing
35
