Kiturami TURBO-21 - 5. Burner Assembly; 5-1 Burner Part Exploded View (17 K, 21 K)

5. Burner Direction for assembly
1). CAPACITY : TURBO - 17K , 21K
NO NO NO
1 2 3
4 5 6
7 8 9
10 11 12
13 14 15
16
BURNER BODY (REAR)
MOTOR COVER
MICAC-RING
OIL SUPPLY PIPE
STABILIZER
IGNITION TRANSFORMER
FAN
5 - 1 Burner Part exploded view
NAMENAME NAME
Nozzle
ELECTRONIC PUMP
PHOTO SENSOR
PEEP HOLE
BURNER BODY (FRONT)IGNITION BAR
MOTOR (BURNER)
NOZZLE HOLDER
