34 35
Fixing the camera to a bike
1. Unscrew both screws (i) and place both halves (ii) of the Bicycle Mount (A)
around the desired position of the pole with the rubber grip in between
the pole.
2. Replacethescrews(i)andtightenthemuntilthemountisrmlyinplace.
3. Remove the screw from the top of the Mount (iii) and slot the camera (inside
waterproof case) into position, replace screw and tighten to lock in position.
4. If you wish to use a forward facing bar you may wish to use the 90º adaptor (iv)
in between the camera and the bicycle mount to make the camera
forward-facing.
iii
iv
ii
i
