Three-phase motor 400 V/ 50 Hz
Supply voltage 400 V/ 50 Hz
The mains connection and the extension cable must be
5-wire=3P+N+SL.-(3/N/PE).
The extension cables must have a minimum cross section
of 1.5 mm².
The mains connection is fused for maximum of 16 A.
Please check the rotational direction, when connecting to
the mains or changing the location. Switch the polarity,
if necessary.
Swap round the poles in the connector plug.
AC motor 230 V/ 50 Hz
Supply voltage 230 V/ 50 Hz.
The mains connection and the extension cable must be
3-wire=P+N+SL.-(1/N/PE).
The extension cables must have a minimum cross section
of 1.5 mm².
The mains connection is fused for a maximum of 16 A.
Maintenance and Repair
Only carry out conversion, adjustment and cleaning work
when the machine is switched off.
Disconnect the appliance.
Skilled mechanics may carry out small repairs on the ma-
chine.
Repair and maintenance work on the electrical system may
only be carried out by qualified electricians.
All protective and safety devices must be immediately re-
placed after repair and maintenance work.
We recommend:
Clean the machine thoroughly after each use!•
Cleaver blade•
The cleaver blade is a wearing part that should be
reground or replaced with a new blade, as required.
Two-hand guard •
The combined clamping and control device must re-
main smooth running. Lubricate occasionally with a
few drops of oil.
Moving parts •
- Keep the cleaver blade guides clean. (Dirt, wood
chips, barks, etc.)
- Lubricate the slide rails with oil spray or lubricating
grease
Checking the hydraulic oil level. •
Check hydraulic fittings and connections for leaks and
wear. If necessary, tighten the bolted connections.
Checking the oil level
The hydraulic system is a closed system with oil tank,
