Furthermore, unapparent risks may remain, despite of •
all the measures taken.
Residual risks can be minimized, if the safety instruc-•
tions, the proper use and the operating instructions
are observed.
Transport instructions
Transport by hand, Fig. 3
To transport the log splitter, completely retract the cleav-
er blade A. Slightly incline the splitter on the cleaver col-
umn, using the handle B, until the machine tilts on to the
wheels and thus can be moved.
Transport by crane:
Never lift by the cleaver blade!
Storage conditions:
Observe the following conditions during storage:
dry, indoor location•
max. humidity 80 %•
Temperaturerange-20°Cto+60°C•
Only operate the machine under the following ambient
conditions:
minimum maximum recommended
Temperature 5C° 40C° 16C°
Humidity 95 % 70 %
Set up
Prepare the location where the machine is to be installed.
Provide sufficient space to ensure safe, trouble-free work-
ing conditions.
The machine is designed for use on level surfaces and
therefore must be set up on a stable, level and firm sur-
face.
Assembly
For packing reasons, your Woodster log splitter is not
completely assembled.
Mounting the wheels, Fig 4.1
Insert the wheel axle with pedal (A) through the two holes
on the oil tank.
Insert the hexagon socket screw M6 (B) through the wheel
axle and tighten it onto the lug (C) with a safety nut.
Then, mount a wheel on each side and secure both with
a cotter pin (D). Slightly bend the cotter pin to prevent it
from falling out.
