DocumentNo.:KE-4025-06                                           23/50



 Assembly
 Assembletheactuatorinaspacious,cleanroom.
 Cleanthepartswithlightoiloracetoneandair-blowthembutneverdipthe
resilientmaterialssuchasOringsinacetoneorotherliquidcleanerlonger
than10minutes.Makethemcompletelydust-free.
 Apply adequate amount of lubricant (KITZ standard Shell Alvania EP2) to
theslidingparts,Oringgroovesandinternalsurfaceofthecylinder.
 Ifanyrustisfoundontheparts,eliminateitcompletely.
 Beforefixingthepistonwithanut,degreasethethreadedportionofthenut
andapplyadequateamountof lockingliquid (KITZstandard:LOCTITENo.
263)topreventloosening.
 ChooseOringsforreplacement,accordingtothedimensionalinformationof
maintenanceconsumablesprovidedinChapter17inthisoperationmanual.
 Carefullyhandlethesealingcomponentstoavoidscratchesordamages.
 Assemblethepistonandpistonrodwithcaresothattheslidingpartsare
notscratchedordamaged.
 Firmlytightenthetierodandboltssothattheymaynotgetloosened.
 After assembly of the actuator, check the valve opening and closing
positionsandattachthepositionindicatortothemountingbracket.

