Kitz B Series - Driving Mechanism

DocumentNo.:KE-4025-06                                           4/50

4DrivingMechanism
4.1TypeBDouble-ActionActuator(SinglePistonTypeCylinder)
Theairpressuresuppliedintotheport〈A〉pushesthepistontotheleftandenergizesitsmovementtorotate
the scotch-yoke counterclockwise. The scotch-yoke converts linear movement of the piston rod to
counterclockwiserotationalmovementoftheshafttoopenorclosethevalve,followingthepresetmode.
Reversesupplyoftheairpressureintotheport〈B〉activatesthereversevalveoperation.Airfailurewillcause
thevalvestayattheposition.










4.2TypeBDDouble-ActionandDoubleCylinderActuator(DoublePistonTypeCylinder)
Theairpressuresuppliedintotheport〈A〉and〈A〉 pushesthepistontotheleftandenergizesitsmovement
torotatethescotch-yokecounterclockwise.Thescotch-yokeconvertslinearmovementofthepistonrodto
counterclockwiserotationalmovementoftheshafttoopenorclosethevalve,followingthepresetmode.
Reversesupplyoftheairpressureintotheport〈B〉and〈B〉 activatesthereversevalveoperation.Airfailure
willcausethevalvestayattheposition.











Pin
Roller
Scotchyoke
 Shaft
Pistonrod
Piston
A
B
A
B
A
’
B’
Fig.2
Fig.3
