Kitz B Series - Standard Technical Specifications

DocumentNo.:KE-4025-06                                           6/50

5.StandardTechnicalSpecifications













OutputTorque
Unit:N-mUnit:N-m




















Operatingmedia Compressedinstrumentationair
Standardoperatingpressure 0.4MPa;factorypresetpressure
Pressuresupplyrange
0.3MPato0.7MPa
Contact KITZ when other than the standard operating
pressureisrequired.
Standarddurability 100,000cyclesundermoderateserviceconditions
Housingtestpressure 0.97MPa
Shaftrotation 90°(±5°)
Servicetemperaturerange
-20℃ to+60℃ 
(Nofreezingofsupplyair)
OperatingPressure
0.4MPa
Type-
Size
0° 45° 90°
B-0 14.0 6.9 14.0
B-1 36.4 18.2 36.4
B-2 94.5 47.2 94.5
B-3 238 119 238
B-4 606 303 606
B-5 1517 758 1517
B-6 3680 1840 3680
B-D6 7365 3683 7365
B-7 9215 4607 9215
B-D7 18444 9222 18444
OperatingPressure
0.4MPa
Type-
Size
Operation
0° 45° 90°
Air 16.7 6.8 10.7
BS-0
Spring 10.5 6.7 16.5
Air 39.1 16.2 25.9
BS-1
Spring 25.8 16.1 38.9
Air 100 41.7 66.3
BS-2
Spring 66.8 41.9 101
Air 265 110 177
BS-3
Spring 178 111 266
Air 685 285 455
BS-4
Spring 452 283 682
Air 1730 720 1151
BS-5
Spring 1150 720 1730
Air 4151 1729 2768
BS-6
Spring 2873 1733 4158
Air 10974 4580 7357
BS-7
Spring 7016 4410 10624
