INSTALLATION OF THE INDOOR UNIT
Important installation instructions
WARNING
Risk of injury! All persons involved in the installation of the air
conditioning system MUST have the valid certi cation of the responsible
authority and the quali cation recognised by this industry for handling
the refrigeration system.
• If other technicians are required for the maintenance and repair of the unit, they
should be supervised by the person who has the quali cation for the use of the
combustible refrigerant.
• The air-conditioning system must only be repaired in accordance with the procedure
laid down by the manufacturer of the appliance.
• The air conditioner must not be operated in rooms with open  ame devices (such as
 replaces, running coal-gas appliances, running heaters, etc.).
• It is not permitted to drill into or expose the connecting pipe to  re.
• The air conditioner must be installed in a room larger than the speci ed minimum
room size. The minimum room size is indicated on the nameplate or in the following
table a.
• A leak test must be carried out after installation of the unit.
Minimum room size (m
2
)
Minimum
room
area (m
2
)
Charge
amount (kg)
≤ 1,2 1,3 1,4 1,5 1,6 1,7 1,8 1,9 2 2,1 2,2 2,3 2,4 2,5
Floor location / 14,5 16,8 19,3 22 24,8 27, 8 31 34,3 37, 8 41,5 45,4 49,4 53,6
Window
mounted
/ 5,2 6,1 7 7,9 8,9 10 11 , 2 12,4 13,6 15 16,3 17, 8 19,3
Wall
mounted
/ 1,6 1,9 2,1 2,4 2,8 3,1 3,4 3,8 4,2 4,6 5 5,5 6
Ceiling
mounted
/ 1,1 1,3 1,4 1,6 1,8 2,1 2,3 2,6 2,8 3,1 3,4 3,7 4
