Notes:
• The air conditioner shall not be used in the laundry.
• The plug shall be accessible after the unit is positioned
Duct mount instruction
• In cooling and drying mode, the exhaust duct needs to be installed while in
fan mode, the exhaust duct is not needed.
• According to the actual needs, the exhaust duct can be moderately
compressed and tensed, but cannot be arbitrarily stretched and bent.
• The exhaust duct can be connected with Windows or installed into the wall.
• With the actual needs, you can make the installation with accessories of the
unit.
1. Install the adaptor A and adaptor B( at mouth or round mouth) onto the
exhaust duct as shown in Fig.A or Fig.B.
A B
Connect the exhaust duct to the Air outlet connector on back of the unit. Slide-in
the adaptor A downwards until it is locked in place. (Fig.C).
C
