Klarstein HEKTOR - INSTALLATION; Mounting Height and Cabinet Cut-out

18
EN
INSTALLATION
1 2
The cooker hood should be placed
65-75 cm (26-30 inches) above the
cooking surface for optimum effect.
Saw a 500*275 mm hole in the
underside of the wall cabinet. Make
sure that the edge of the hole is at least
35 mm from the edge of the cabinet.
