ELECTRICAL SPECIFICATIONS
Function Range Resolution Accuracy
AC Voltage
(V AC)
600.0V 0.1V ±(1.2% + 3 digits)
Input Impedance: ≥10MΩ Frequency Range: 40 to 400Hz
Maximum Input: 600V AC RMS or 1000V DC
Accuracy specified from 5% to 100% of the measuring range
DC Voltage
(V DC)
6.000V 0.001V
±(0.8% + 3 digits)60.00V 0.01V
600.0V 0.1V
1000V 1V ±(1.0% + 5 digits)
Input Impedance:
≥
10MΩ Maximum Input: 600V AC RMS or 1000V DC
Accuracy specified from 5% to 100% of the measuring range
AC Current
(A AC)
0.2 – 2.0A 0.1A ±(1.8% + 2 digits)
2.1 – 5.0A 0.1A ±(1.8% + 3 digits)
5.1 – 200.0A 0.1A ±(1.8% + 5 digits)
Frequency Range: 50 to 60Hz
Accuracy specified from 5% to 100% of the measuring range
Resistance
600.0Ω 0.1Ω ±(1.2% + 2 digits)
6.000kΩ 1Ω
±(1.0% + 2 digits)60.00kΩ 10Ω
600.0kΩ 100Ω
6.000MΩ 1kΩ ±(1.2% + 2 digits)
60.00MΩ 10kΩ ±(1.5% + 5 digits)
Maximum Input: 600V AC RMS or 1000V DC
OTHER MEASUREMENT APPLICATIONS
• Continuity Check: Audible signal <10Ω, test current <1.5mA
• Non-Contact Voltage Testing (NCV): Audible & Visual indicators sound /
illuminate for >70V AC RMS at distances <10mm from the source
• Auto Power off: After 15 minutes of inactivity
• Backlight Auto off: After 3 minutes of inactivity
• Overload:
Buzzer sounds continuously for voltage >600VAC or >1000VDC,
"OL" indicated on display for voltage >610VAC or >1010VDC
• Sampling Frequency: 3 samples per second
• Polarity: "-" on display indicates negative polarity
• Display: 3-5/6 digit, 6000 Count LCD
