F. Backlight
• Press to enable/disable lights.
• Using lights drains the battery significantly.
G. H. Battery/Fuse Replacement
• When
indicator is displayed on the LCD, batteries must be
replaced.
• Remove back screw and replace 9V battery.
• If more than 400mA is applied to
A
, replace with 400mA/250V
fast-blow fuse.
• If more than 10A is applied to
B
, replace with respective
10A/500V fast-blow fuse.
Auto Power-Off
• Device will power off after 15 minutes non-use.
• Turn the dial or press a button to wake.
A. B. Use properly safety-rated leads.
A. Do not attempt to measure more than 600V or 400mA.
B. Do not attempt to measure more than 10A.
C. Select Functionality Button
• Switch between AC and DC.
• Switch between
and .
D. Data Hold
• Press to hold the current input on the display.
• Press again to return to live reading.
E. Select Frequency/Duty Cycle Button
• Switch between measurement, Hz, and %.
COM
m
10A/250V
~
400mA/250V
~
600V MAX
Temp
FUNC.
HOLD
MM200
H
z%
mA
A
µA
Temp
H
z%
B
C
On Back
E
A
H
F
D
G
• Select AC or DC voltage source.
2. AC / DC Current (large): < 10A
1. AC / DC Voltage: < 600V
• Start with this setting if current level is unknown.
• Attach red lead to “10A” input.
• Select AC or DC current source.
• Current above 10A will require fuse replacement.
FUNC.
PRESS
AC
DC
FUNC.
PRESS
AC
DC
FEATURE DETAILS
SYMBOLS
~
AC Alternating Current Warning or Caution
DC Direct Current Dangerous Levels
DC/AC Voltage or Current Double Insulated Class II
Ground AC Source
H
z%
mA
A
µA
Temp
3
5
6
2
1
4
7
8
