klover BI-FIRE MID - Technical Features

6
Technical features
Total nominal heat output
kW (Kcal/h)
33,2 (28.600)
Pellet nominal heat output
kW (Kcal/h)
16,5 (14.200)
Wood nominal heat output
kW (Kcal/h)
16,7 (14.400)
Total power given-up to the heating water
kW (Kcal/h)
20,4 (17.500)
Pellet power given-up to the heating water
kW (Kcal/h)
10,7 (9.200)
Wood power given-up to the heating water
kW (Kcal/h)
9,7 (8.300)
Total power given-up to the environment due to radiation
kW (Kcal/h)
7,3 (6.300)
Pellet power given-up to the environment due to radiation
kW (Kcal/h)
4,3 (3.700)
Wood power given-up to the environment due to radiation
kW (Kcal/h)
3 (2.600)
Pellet yield
%
90.8 (90.7)
Wood yield
%
76.3
Nominal voltage
V
230
Nominal frequency
Hz
50
Expansion vessel lt/preloading bar
8 / 1
Maximum working pressure/recommended
bar
2.5 / 1.5
Minimum pellet chimney effect
Pa
12
Minimum wood chimney effect
Pa
12
Pellet tank capacity
Kg
30
Pellet min – max hourly consumption
Kg/h
1 / 3.4
Hourly consumption of wood
Kg/h
3.7
Wood loading interval
min
54
Boiler body capacity
litres
50
Width
mm
820
Height
mm
1080
Depth
mm
600
Minimum safety distance from flammable materials
mm
200
Weight of version with majolica sides
Kg
290
Weight of version with painted steel sides
Kg
280
The given heat power can change according to the pellet and wood used.
Pellet features
The thermo stove has been tested with all types of pellets present on the market. The pellets used must have the following features:
 Diameter 6 mm;
 Maximum length 35 mm;
 Maximum humidity content 8 – 9 %;
 100% wood. Total absence of additives.
 1.1 % maximum ash residue
For good thermo stove efficiency, we recommend the use of good quality pellets. Pellets must be poured into the tank using a shovel and not
directly from the bag.
In order to recognise pellet of quality it is necessary that:
 It is manufactured with constant diameter cylinders and it has a smooth and glossy surface;
 There is not a lot of sawdust inside the packaging;
 If the pellet is poured into a container of water it will tend to sink if it is a quality pellet, while if it is not, it will tend to float;
 The conditions of the quality certification and in particular the compliance with international Standards such as EN 14961-2 Wood pellet class A1-A2
(maximum moisture level of 10%), should be indicated on the packaging;
 Packages are intact since pellets tend to absorb humidity. Humidity not only reduces the calorific value and increases exhaust gas, but it also swells
the product which could create problems in the thermo stove.
International Standards must be respected for the manufacturing of pellets as in France, Austria, Germany and recently some countries from Eastern,
also must comply with the EN14961-2, DIN 51731 and the O-NORM M7135 Standards in the production phase. These Standards establish the minimum
values in order to check pellet quality. In Italy there is no official Standard, but it is recommended to use pellets that respect the previously-mentioned
Standards.
The use of poor pellets or pellets made of any other material can lead to damage of the thermo stove functions and can also make the warranty
null and void and make the manufacturer exempt from all responsibility.
In order to guarantee combustion without problems the pellets must be kept in a dry place.
