klover BI-FIRE MID - Connections data sheet

5
ENGLISH
Clearance
820
215
228
600
1080
Connections data sheet
R
M
A
X
VISTA
POSTERIORE
C
F
180
250
455
500
580
820
70
110
80
140
160
1140
M = Ø 3/4" F SYSTEM DELIVERY
R = Ø 3/4" M SYSTEM RETURN
C = Ø 14mm DOMESTIC HOT WATER OUTLET (on prepared models only)
F = Ø 14 mm DOMESTIC COLD WATER INLET
A = Ø 44 mm AIR SUCTION DEVICE (pellet side)
X = Ø 3/4" M BOILING DISCHARGE
REAR VIEW
