STYLE 140, STYLE 180, STYLE 220 PELLET STOVE
42
EN - Rev. 1.2
Parameters “DEFAULT SETTINGS” - Mod. SL180 (N04_071119)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
n0
Pr01
M08 – 6 – 01
Ignition cycle maximum time
IGNIT- MINUTES
Minutes
5 – 25
18
Pr02
M08 – 6 – 02
Start time
START MINUTES
Minutes
2 – 12
8
Pr03
M08 – 6 – 03
Time interval between the two brazier cleaning operations
BRAZIER CLEANING
Minutes
3 – 240
50
Pr04
M08 – 6 – 04
Screw feed gear motor ON time in ignition phase
IGNIT SCREWS
Seconds
0.1 – 8.0
1.2
Pr05
M08 – 6 – 05
Screw feed gear motor ON time in start phase
START SCREW
Seconds
0.1 – 8.0
0.8
Pr06
M08 – 6 – 06
Screw feed gear motor ON time in power 1 work phase
OUTPUT 1 SCREW
FEED
Seconds
0.1 – 8.0
2.4
Pr07
M08 – 6 – 07
Screw feed gear motor ON time in power 2 work phase
OUTPUT 2 SCREW
FEED
Seconds
0.1 – 8.0
3.4
Pr08
M08 – 6 – 08
Screw feed gear motor ON time in power 3 work phase
OUTPUT 3 SCREW
FEED
Seconds
0.1 – 8.0
4.5
Pr09
M08 – 6 – 09
Screw feed gear motor ON time in power 4 work phase
OUTPUT 4 SCREW
FEED
Seconds
0.1 – 8.0
5.6
Pr10
M08 – 6 – 10
Screw feed gear motor ON time in power 5 work phase
OUTPUT 5 SCREW
FEED
Seconds
0.1 – 8.0
6.8
Pr11
M08 – 6 – 11
Alarm delay
ALARM DELAY
Seconds
0 – 120
90
Pr12
M08 – 6 – 12
Brazier cleaning duration
BRAZIER CLEANING
Seconds
0 – 120
60
Pr13
M08 – 6 – 13
Flue gas minimum temperature for considering the stove on
MINIMUM THRESHOLD
°C
40 – 600
160
Pr14
M08 – 6 – 14
Flue gas maximum temperature
MAXIMUM
THRESHOLD
°C
200 – 880
800
Pr15
M08 – 6 – 15
Flue gas temperature threshold for starting the air exchangers
(NOT USED)
BLOWER THRESHOLD
°C
200 – 720
240
Pr16
M08 – 6 – 16
Flue gas extraction speed in ignition phase
IGNIT FL GAS SPEED
RPM
500 – 2800
2100
Pr17
M08 – 6 – 17
Flue gas extraction speed in start phase
START FLUE GAS
SPEED
RPM
500 – 2800
1900
Pr18
M08 – 6 – 18
Flue gas extraction speed in power 1 work phase
P 1 FLUE GAS SPEED
RPM
500 – 2800
1650
Pr19
M08 – 6 – 19
Flue gas extraction speed in power 2 work phase
P 2 FLUE GAS SPEED
RPM
500 – 2800
1750
Pr20
M08 – 6 – 20
Flue gas extraction speed in power 3 work phase
P 3 FLUE GAS SPEED
RPM
500 – 2800
1850
Pr21
M08 – 6 – 21
Flue gas extraction speed in power 4 work phase
P 4 FLUE GAS SPEED
RPM
500 – 2800
2000
Pr22
M08 – 6 – 22
Flue gas extraction speed in power 5 work phase
P 5 FLUE GAS SPEED
RPM
500 – 2800
2150
Pr23
M08 – 6 – 23
Heat exchanger 1 motor speed in power 1 work phase
(NOT USED)
AIR 1 SPEED
Volt
65 – 225
185
Pr24
M08 – 6 – 24
Heat exchanger 1 motor speed in power 2 work phase
(NOT USED)
AIR 2 SPEED
Volt
65 – 225
190
Pr25
M08 – 6 – 25
Heat exchanger 1 motor speed in power 3 work phase
(NOT USED)
AIR 3 SPEED
Volt
65 – 225
195
Pr26
M08 – 6 – 26
Heat exchanger 1 motor speed in power 4 work phase
(NOT USED)
AIR 4 SPEED
Volt
65 – 225
200
Pr27
M08 – 6 – 27
Heat exchanger 1 motor speed in power 5 work phase
(NOT USED)
AIR 5 SPEED
Volt
65 – 225
205
Pr28
M08 – 6 – 28
Threshold beneath which the appliance is considered to be OFF
THRESHOLD OFF
°C
80 – 600
140
Pr29
M08 – 6 – 29
Flue gas extraction speed in brazier cleaning phase
EXHMOTOR
CLEANING
RPM
500 – 2800
2800
Pr30
M08 – 6 – 30
Screw feed gear motor ON time in cleaning phase
SCREW CLEANING
Seconds
0.0 – 8.0
1.8
Pr31
M08 – 6 – 31
Flue gas extractor encoder enable
(NOT USED)
ENCODER
On – off
On – Off
On
Pr32
M08 – 6 – 32
Screw feed brake time
BRAKE TIME
Seconds
0.0 – 0.5
0.2
Pr33
M08 – 6 – 33
Pump activation threshold
PUMP THRESHOLD
°C
20 – 70
55
Pr34
M08 – 6 – 34
Water pressure switch enable
(NOT USED)
WATER MANOSTAT
On – off
On – Off
On
Pr35
M08 – 6 – 35
Water pressure threshold
(NOT USED)
PRESSURE
THRESHOLD
Bar
1.5 – 3.0
2.5
Pr36
M08 – 6 – 36
Screw feed motor reducer ON time in DHW output working mode
DHW SCREW FEED
Seconds
0.1 – 8.0
6.8
Pr37
M08 – 6 – 37
Flue gas intake speed in DHW output working mode
DHW FLUE GAS DEV
RPM
500 – 2800
2150
