Parameter tables STYLE 220
Parameters “VARIOUS SETTINGS” - Mod. SL220 (N04_071119)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
n0
Pr38
M08 – 4 – 01
Re-ignition block
RE-IGNIT
BLOCK
Minutes
0 – 10
6
Pr39
M08 – 4 – 02
Flue gas extractor switch-off time
MIN-EXT OFF
Minutes
0 – 20
10
Pr40
M08 – 4 – 03
Pre-loading time in ignition
IGNIT PRE-
LOAD
Seconds
0 – 255
120
Pr41
M08 – 4 – 04
Stand-by time after pre-loading
AFTER-PRE
STAND-BY
Seconds
0 – 255
80
Pr42
M08 – 4 – 05
Extractor speed in pre-loading phase
FLUE GAS-
EXT
PRELOAD
RPM
350 – 2800
2100
Pr43
M08 – 4 – 06
ON/OFF temperature hysteresis on “SET H2O”
DELTA ON
OFF AUTO
°C
0.0 – 20.0
5.0
Pr44
M08 – 4 – 07
Delay at economy operation mode switch-off (timer after exceeding “SET H2O
+ Pr43”)
DELAY-OFF
AUTO
Minutes
2 – 120
10
Pr45
M08 – 4 – 08
Power change delay
POWER
CHANGE
Seconds
0 – 60
20
Pr46
M08 – 4 – 09
ON/OFF Temperature hysteresis on “SET ROOM”
DELTA ON
AUTO
°C
0.0 – 15.0
2.0
Pr47
M08 – 4 – 10
Keypad lock enable
KEY LOCK-EN
On – off
On – off
Off
Pr48
M08 – 4 – 11
Time after which an alarm is triggered in the event of a blackout
BLACKOUT
ALARM
Seconds
0 – 60
30
Pr49
M08 – 4 – 12
Pellet level sensor enable and type
PELLET
RESERVE
Off / Type
“Off” disabled
“Opt” optical
“Cap” capacitive
Off
Pr50
M08 – 4 – 13
Pump start threshold and power modulation for overheating safety
PUMP
SAFETY
°C
60 – 90
80
Pr51
M08 – 4 – 14
3-way switching and re-ignition delta on “SET BOILER” and “SET PUFFER”
DELTA PUF-
BOI
°C
0 – 15
5
Pr52
M08 – 4 – 15
Preheating time
PRE-HEAT
TIME
Seconds
0 – 480
0
Pr53
M08 – 4 – 16
Extractor speed in preheating phase
PRE-HEAT
GAS SPEED
RPM
500 – 2800
2800
Pr54
M08 – 4 – 17
Time after which the “NO PELLET” alarm is triggered if “PELLET RESERVE”
RESERVE
ALARM
Minutes
1 – 180
180
Pr55
M08 – 4 – 18
ON time for turbulator cleaning gear motor
TURBOLAT
DURATION
Seconds
0 – 600”
0
Pr56
M08 – 4 – 19
ON time for brazier cleaning gearmotor
(NOT USED)
CLEANING
TIME
Seconds
0 – 120”
13
Pr57
M08 – 4 – 20
Time from switching off after which the brazier cleaning takes place (NOT
USED)
CLEANER
DELAY
Minutes
1 – 15’
6
Pr58
M08 – 4 – 21
Time from switching on after which the brazier cleaning cycle starts
(NOT USED)
CLEANER
STAND-BY
Hours
1 – 24
10
Pr59
M08 – 4 – 22
Pump activation threshold and switching 3-way valve in DHW OUTPUT MODE
(with Type 2 System)
PUMP
THRESHOLD
I2
°C
55 – 75
60
Pr142
M08 – 4 – 23
Temperature differential between“SET H2O” and “SET BOILER” or “SET PUFFER”,
above which the appliance operates in economy mode
DELTA
MODULA
°C
1 – 10
5
Pr143
M08 – 4 – 24
Maximum H2O temperature threshold, over which the appliance will shut down
independently of other conditions
MAX H2O
THRESHOLD
°C
81 – 85
85
