STYLE 140, STYLE 180, STYLE 220 PELLET STOVE
5
EN - Rev. 1.2
The images below show certain details of the appliance:
Return pipe.
Delivery pipe.
Display.
Opening
for optional connection to
safety valve.
Hook for cleaning the
front heat exchanger.
Intake pipe.
Flue gas outlet.
R.T. terminal for room
thermostat connection.
Anti-interference filter.
Main switch, connection for
power supply cable with 2
built-in fuses (4A 250V).
Safety thermostat with
manual reset.
Terminal
for optional connection to
puffer / boiler probe.
CE label
with technical data, serial
number and model.
Upper knobs
for cleaning internal flue
gas turn.
REAR VIEW
TOP VIEW
