Panel implements following tasks:
1. Fuel type selection – pressing button (B) causes the transition from one fuel to another
(petrol - gas - petrol)
2. Working state indication (C).
Work on petrol – gas system is completely shut down, the panel is completely blank -
no lights are flashing. The backlight diode for the DG7 panel may be on.
Work on petrol with the function of waiting for a switch to gas – flashing fuel level and
level LED's. The system is waiting for parameters to switch. If the reducer temperature is
lower than required for switching, it will be signaled by the fuel level LED's.
Work on gas – permanently illuminated status LED (selectable during the calibration of
the system).
Work on gasoline with the auto-return – if conditions occur during gas operation that
cause switching to petrol, the panel will start blinking with the status LED and the status
level LEDs. WARNING! The auto-return signaling function can be disabled in the
configuration program.
2.1 Indication of the current level of gas fuel in the tank (A)
Number of illuminated LEDs of gas level display indicates the degree of filling the gas
tank:
Flashing red LED
(or 1 green + 1 red)
2.2 Light sensor (NEVO and NEVO-SKY only)
Depending on the ambient light controller automatically adjusts the brightness of the
panel (configurable option in the program).
2.3 Gas system signaling
Sequential gas injection system Diego G3 / NEVO / NEVO-SKY has the function of self-
control, allowing to detect malfunctions of the gas installation. All errors are stored in the
