KMT Streamline SL-V 60 Plus User Manual

Section 10
Troubleshooting
20413005
8-2012/Rev 05
10-2
10.2 Troubleshooting Guide
Listen to the machine and observe it in operation. Learn to recognize the normal sounds and
operating conditions of the system. Carefully define the symptom of the problem. Locate the
symptom on the troubleshooting guide that most closely corresponds to the problem.
If the symptoms in the guide do not correspond to the malfunction, or if the problem is not
resolved by the recommended corrective action, contact the KMT Customer Service Department
for assistance.
Table 10-1
SL-V Series Troubleshooting Guide
Malfunction Indication Comments
1.
High boosted water
temperature
Orifice is blocked with debris
Long deadhead condition
Insufficient water supply
Booster pump temperature
switch malfunction
2.
Booster pump pressure
drop is greater than 30 psi
(2 bar) during stroke
condition
Inlet water pressure or flow is
low
Filter element is dirty and
needs to be replaced
Booster pump is starting to
fail
If the pressure consistently
drops below 60 psi (4 bar) the
pump will need to be replaced.
3.
Outlet booster pump
pressure is falling below 60
psi (4 bar)
Inlet water pressure is low
Filter element is dirty and
needs to be replaced
Booster pump needs to be
adjusted, or replaced
Booster pump should be
adjusted to 120 psi (8 bar) when
deadheaded.
4.
Inlet water flow is poor and
the filter housing is not
filling completely
Pipe sizing for inlet cutting
water should be checked for
pressure and flow
Cutting water supply will be
lacking capacity or flow.
5.
Water is leaking around the
cap nut on the filter head
Gasket that closes the passage
has deteriorated
A gasket under the cap nut can
deteriorate causing the passage
to remain open. The gasket can
be replaced by removing the cap
nut.
