Section 11
Specifications
20413013
8-2012/Rev 10
11-2
Sound Level
30 HP 50 HP 60 HP 100 HP
Sound level [dB(A)] 72.5 72.5 77.5 77.5
Equipment Dimensions and Weights
Horsepower Length Width Height Weight
30 HP 67.98” (1,727 mm) 36.00” (914 mm) 57.19” (1,453 mm) 1,920 lbs (870 kg)
50 HP 67.98” (1,727 mm) 36.00” (914 mm) 57.19” (1,453 mm) 2,720 lbs (1,234 kg)
60 HP 67.98” (1,727 mm) 36.00” (914 mm) 57.19” (1,453 mm) 3,220 lbs (1,460 kg)
100 HP 77.75” (1,975 mm) 36.00” (914 mm) 57.19” (1,453 mm) 4,200 lbs (1,905 kg)
Redundant Models (same dimensions as above)
30 HP 2,200 lbs (998 kg)
50 HP 3,000 lbs (1,360 kg)
60 HP 3,500 lbs (1,588 kg)
100 HP 4,600 lbs (2,087 kg)
Service Connections
Connection Height
A Drain 1/2” NPT 7.50” (191 mm)
B Cutting Water In 1/2” NPT 10.50” (267 mm)
C Cooling Water In (oil-to-water models) 1/2” NPT 13.50” (343 mm)
Hydraulic Oil In (air-to-water models) 3/4” JIC
D Cooling Water Out (oil-to-water models) 1/2” NPT 16.50” (419 mm)
Hydraulic Oil Out (air-to-water models) 3/4” JIC
E Plant Air In 1/4” NPT 32.00” (813 mm)
F Cutting Water Out 9/16” HP 36.00” (914 mm)
G Contaminated Waste Drain 1/2” NPT 41.00” (1,041 mm)
All service connections are made on the rear bulkhead of the machine. The intensifier requires
two incoming water sources, cooling water and cutting water; two drain lines, cooling water and
wastewater; a high pressure discharge line, and an air supply line.
