Section 12

Parts List

20413146

8-2012/Rev 12

12-4

Table 12-1

SL-V 100 Horsepower Intensifier Unit

Item

Part

Number Description Quantity

1 20429831 High Pressure Piping Assembly 1

2 49830938 Electrical Assembly 1

3 20431316 Redundant Kit (Optional) 1

4 20461179 Decal Package, 100 Horsepower Single 1

5 05128087 Startup Tag 1

6 80079668 Bulkhead Pipe Assembly 1

7 05141569 Frame Assembly 1

8 05104153 Reservoir Assembly 1

9 80074768 Cover Assembly 1

10 49835846 Hydraulic Power Package 1

11 05142351 Hydraulic Hose Connections 1

12 20461257 Striping, Red 45.0”

13 10097657 Button Head Screw, 1/4-20 x 3/4 4

14 95391322 Flat Washer, .25 4

15 95838314 Lock Washer, .25 4
