MedVault® 2.5 | USER GUIDE
KNOX COMPANY | 800-552-5669 | TECHSUPPORT@KNOXBOX.COM | KNOXBOX.COM | OPE-MVUSER-0471-B | PAGE 8 of 15
6. If you are connecting the unit with continuous power:
A. First, connect ground to the black wire.
B. Second, power +12 volts to the red wire.
7. Test the installation by turning on the power. The keypad should be lit and a banner should scroll above
it, displaying the door status.
Note: For additional information, consult the MedVault Installation Guide
Removing the Door
MedVaults ship fully assembled. Doors are removable for repair of door components. To remove the door:
1. Open the door with a PIN code or turn off power to the unit and open the door with the override key.
2. Use a screwdriver to remove the wire access panel.
3. Disconnect the coax connector and the Microfit connector.
4. Use the Knox security screw removal bit to unscrew the two screws in the hinge lock.
