CoolAdd
®
Manual / Bedienungsanleitung
CoolAdd 01.998.350.0 issue a page / Seite 18/59
The cooling water pi pes have to be insulated to avoid condensation and losses using
a waterproof isolation.
Insulation thickness : „F“ (9 - 12mm)
= 0,037 W/mK (10°C)
5.4 Condensed water connection
If the CoolAdd is operating below dew poi nt, condensed water may form. There
is a standard condensed water connection, 10mm diameter, in the condensed
water tray for drainage.
Ensure that the condensed water pi pe has a drop. The condensed water drain is
not pressurised. An optional condensed water pump can be used.
5.5 Electrical connection
The electrical connection is achieved by usi n g a free socket in the existing
cabinet. Use fuses as specified to technical data on point 3.4.
Connecting cable with
plug)*
Existing
server cabinet
CoolAdd
Heat exchanger part
