PACKAGE CONTENTS
A
B
C
E
F
J
G
I
L
K
PART DESCRIPTION PART DESCRIPTION
A Lock-off button I Front-assist handle
B Variable-speed trigger switch J Adjusting lever
C Rear handle K Screw knob
D Hinge L Guard
E Trimmer shaft M Line-cutting blade
F Trimmer head unit N Screws (ST4x16) (2)
G Bump head O Screws (ST4.8x19) (2)
H Speed mode switch
WARNING
• Remove the tool from the package and examine it carefully. Inspect the tool carefully to
make sure that no breakage or damage occurred during shipping. If any parts are damaged
or missing, please return the product to the place of purchase. Do not discard the carton or
any packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not attach the battery to use the tool until
the part has been repaired or replaced. Failure to heed this warning could result in serious
injury.
