16
OPERATING INSTRUCTIONS
3. Attaching/Removing Battery Pack
To Attach Battery Pack
a. Align the raised portion on the battery pack
with the grooves on the bottom of the tool, then
slide the battery pack onto the tool, as shown.
b. Make sure that the latches on the battery pack
snap into place and the battery pack is secured
to the tool before beginning operation.
NOTICE: When placing the battery pack on the
tool, be sure that the raised rib on the battery pack
aligns with the groove on the tool and the latches
snap into place properly. Improper assembly of
the battery pack can cause damage to internal
components.
To Detach Battery Pack
a. Press the battery-release buttons to release the battery pack.
b. Pull backward on the battery pack to remove it from the tool.
WARNING
• Battery tools are always in operating condition. Therefore, always remove the battery pack
when the tool is not in use or when carrying the saw at your side.
4. To Start/Stop the Pruning Saw
a. To turn the saw ON, grasp the handle (A) rmly
with one hand.
b. Press the lock-off button (C), and then squeeze
the trigger switch (B).
WARNING
• Make sure no objects or obstructions, which
could come in contact with the bar and chain, are
in the immediate vicinity.
c. To turn the saw OFF, release the trigger switch
and allow the chain to come to a complete
stop.
3
Battery-release
buttons
4
A
C
B
