15
OPERATING INSTRUCTIONS
h. Align the notches of the spool from which the
lines protrude with the eyelets in the spool
retainer and position the spool in the retainer
(Fig.8d).
i. Holding the spool and spool retainer, grasp
one end of the line and pull it to release the
line from the notch in the eyelet (Fig. 8e).
Repeat with the other end.
j. With the spool base facing downward, align
the slots in the spool retainer with the tabs on
the spool base and press the retainer evenly
down until it snaps into place (Fig. 8f).
NOTICE: Make sure that the tabs on the spool
base snap into place or the spool will come out
during operation.
8d
8e
8f
Tap
Slot
