KIMA00H1 (0204)
12
FIGURE 13
FIGURE 14
FIGURE 15
MOUNTING BRACKETS
TO OPEN PANELS
FOR INSPECTION,
PULL OUT TOP EDGE
THEN LIFT PANEL UP
COMPRESSOR SECTION
ACCESS PANEL
STARTER SECTION
ACCESS PANEL
SPACER BLOCKS
SPREADERS
SPACER BLOCKS
