KIMA00H1 (0204)
14
FIGURE 16 - REAR VIEW
FIGURE 17 - INSURE ADEQUATE VENTILATION FOR COMPRESSOR
COOLING AIR
OUTLET
COOLING AIR
INLETS
MOISTURE
SEPARATOR
SERVICE VALVE
FLEXIBLE
CONNECTOR
AIR SYSTEM
PIPING
COMPRESSOR
AIR INLET
VENTILATION
AIR OUT
VENTILATION
AIR IN
COMPRESSOR
ROOM
REMOVE PLUG TO VIEW
MAIN MOTOR ROTATION
