KIMA00H1 (0204)
26
FIGURE 27 - BACK OF DISPLAY
FIGURE 28 - ACCESS PANELS FOR ELECTRICAL CONTROLS
PLC ACCESS PANEL
STARTER ACCESS PANEL
DISPLAY POWER
CONNECTOR
COM PORT
(
RS-422
)
COM PORT
(
RS-485
)
COM PORT
TO PLC
(RS-232)
MOUNTING CLIPS (6)
