Kobelco KNW Series User Manual

KIMA00H1 (0204)
28
FIGURE 29A - PLC
FIGURE 29B - PLC WITH COVERS REMOVED
TERMINAL COVER
HINGES DOWN
PLC CPU
STATUS LED’s
PLC INPUT
LED’s
TERMINAL COVER
HINGES UP
PLC OUTPUT
LED’s
PULL OUT AT TOP
TO REMOVE
PROCESSOR COVER
PLC-X1
OUTPUT MODULE
OUTPUT
LED’s
PLC-B
BASE WITH
POWER SUPPLY
PLC-X2
ANALOG MODULE
STATUS
LED’s
PLC-X3
ANALOG MODULE
PLC
END CAP
TERMINAL COVERS
HINGE RIGHT
PLC-C
PROCESSOR
COVER
HINGES
PLC INPUTS
PLC OUTPUTS
COM PORT 0
COM PORT 1
RUN-REM-PROG
SWITCH
EPROM
MODULE
BATTERY
BATTERY CLIP
F
O
R NEW BATTERY
BATTERY CONNECTOR
FOR NEW BATTERY
LEVER FOR
MODULE
CONNECTOR
MOUNT CLIP
SCREW
MOUNT CLIP
SCREW
