KIMA00H1 (0204)
32
FIGURE 32 - REAR VIEW OF COMPRESSOR
FIGURE 33 - FRONT VIEW, INSIDE OF COMPRESSOR
INTAKE AIR
DUST FILTERS
CONDENSATE
DRAIN VALVES
INLET AIR
FILTER
LUBRICATION
OIL FILTER
OIL DRAIN
VALVE
OIL LEVEL SIGHT
GAUGE
LOAD CONTROL
SOLENOID VALVE
READ OPERATING PARAMETERS
GT-TERMINAL
