KIMA00H1 (0204)
4
FIGURE 4 - COOLING AIR FLOW
FIGURE 5 - LUBRICATION OIL FLOW DIAGRAM
AFTERCOOLER EXHAUST
AIR DUCT
AIR
OUTLET
COOLING
FAN
OIL
COOLER
INTERCOOLER
AIR INLET
(REAR)
AFTERCOOLER
AIR DUCT
