Chapter 7
38 Kodak ESP·3 All-in-One
Replacing the printhead
If your printhead is damaged or broken it is easy to replace yourself.
1 Make sure the Kodak ESP 3 All-in-One printer is on.
2 Open the printer access door.
3 Pinch the latch on the ink cartridge with your thumb and forefinger and lift it out of the
printhead. Remove both ink cartridges.
4 Unlatch the printhead by pressing the release button at the top centre of the carriage.
5 Remove the old printhead from the carriage.
