A-62051 May 2008 15
Operating the Archive Processor
Attaching film to a
take-up reel
As processed film exits the Archive Processor, you must attach it to a
take-up reel. There are different ways to attach film to a take-up reel,
depending on the type of reel you are using. One way is to use a trailer
holder (snubber). Another way is to wrap the film around the center of
the reel. Both ways are described in this section.
NOTE: Kodak no longer supplies this reel with a separate trailer hold.
Kodak supplies only the integral film cinch pin as shown below.
Using a trailer holder 1. Wrap the film counterclockwise around a trailer holder (snubber).
2. Wrap the film around the trailer holder one more time.
3. Insert the trailer holder (snubber) in the core of the take-up reel.
4. Insert the film in the slot of the take-up reel.
Film
Film Reel
Trailer Holder
Slot
