2 A-62051 May 2008
Specifications
Archive Processor 220-240 V Archive Processor 120 V
Power
requirements
220 to 240 VAC, 50 Hz, single phase,
7.5 amp
Two-prong electrical plug with ground
connection
120 VAC, 50 Hz, single phase, 12 amp
120 VAC, 60 Hz, single phase, 12 amp
Three-prong electrical plug with ground
connection
Dimensions and
weight
Height: 91 cm (36 in.) with the cover open
Length: 110 cm (43 in.) with reel on take-up
spindle
Depth: 56 cm (22 in.) with the cover open
Weight: 52.2 kg (115 Ib) empty
63.5 kg (140 Ib) with chemicals,
water, and processing racks
Support: Table or stand between
53 and 68 cm (21 and 27 in.) high
Height: 91 cm (36 in.) with the cover open
Length: 99 cm (39 in.) without reel on
take-up spindle
110 cm (43 in.) with large reel on
take-up spindle
Depth 61 cm (24 in.) with the cover open
Weight: 52.2 kg (115 Ib) empty
63.5 kg (140 Ib) with chemicals,
water, and processing racks
Support: Table or stand between
53 and 68 cm (21 and 27 in.) high
Operating
environment
Ambient Temperature: 18.5 to 30°C
(65 to 86°F)
Relative Humidity: 20 to 76%
Ambient Temperature: 18.5 to 30°C
(65 to 86°F)
Relative Humidity: 20 to 76%
Heat emissions
Maximum: 5100 BTU (5380 Kjoules)
Standby: 350 BTU (366 Kjoules)
Processing Film: 4100 BTU (4325 Kjoules)
Maximum: 5100 BTU (5380 Kjoules)
Standby: 350 BTU (366 Kjoules)
Processing Film: 4100 BTU (4325 Kjoules)
Noise emission
Operator Position Standby Mode
• Sound Pressure Level (L
A
): 51.2 dB(A)
Operator Position Full System
Operating Mode
• Sound Pressure Level (L
A
): 59.3 dB(A)
• Instantaneous Peak Values 130 dB(C):
None
• Sound Power Level (L
WA
)
• Standby: 63.4 dB(A)
• Full System: 69.6 dB(A)
Operator Position Standby Mode
• Sound Pressure Level (L
A
): 51.2 dB(A)
Operator Position Full System
Operating Mode
• Sound Pressure Level (L
A
): 59.3 dB(A)
• Instantaneous Peak Values 130 dB(C):
None
Sound Power Level (L
WA
)
• Standby: 63.4 dB(A)
• Full System: 69.6 dB(A)
