Kodak RVG 6500 IPS System Safety, Regulatory & Technical Specification User Guide

22 Chapter 3 Technical Specifications
WiFi Network Technical Specification
Item
Specification
Network Protocol TCP/IP
Network Type Private Wireless LAN (WLAN)
Network Mode Infrastructure mode
Wireless Protocol 802.11g
Frequency band 2.4 GHz ISM radio band
Modulation OFDM
Data rated (measured) Up to 10Mbps
Number of channels
• 11 for USA & Canada
• 13 for Europe
• 14 for Japan
Maximum Power 20 mW
IP Address
The KODAK RVG 6500 / KODAK RVG
6500 IPS client acts as a DHCP. Client
DHCP server is embedded within the
Access Point.
Data Size (maximum) One 5.4 MByte file
Security
WEP 128-bit encryption Factory loaded key
Private Patient Identification Data No patient ID data transmitted
Environmental Specifications
Operating temperature 0° to 40° C
Range Up to 10m
